DELIVERY DATE

JULY 2011 HYUNDAI MIPO SHIPYARDS

TYPE

SUPRAMAX BULK CARRIER

DWT

57414 DWT (SUMMER)

DRAFT

13.019 MT

GRT / NT

INT 31901 / 19014

FLAG

MARSHALL ISLANDS

CLASS

ClassNKK

LOA

193.07 M

LBP

185 M

BREADTH

32.26 M

MAIN ENGINE TYPE

HYUNDAI-B&W 7S50MC-C8 9750 KW 121.8.RPM

AUXILIARY ENGINE & GENERATOR

HYUNDAI HIMSEN / 6H17-28 x 690 Kw, 3 PCS.

DEPTH, MOULDED

18.50 MT

DESIGNED DRAUGHT, MOULDED

11.10 MT

SCANTLING DRAUGHT, MOULDED

13.00 MT

DEADWEIGHT ON SCANTLING DRAUGHT MOULDED

57414 MT

CAPACITY

72868.6 M3

CARGO HANDLING CRANE & GRAB

SWL 30 T MACGREGOR ELECTRO-HYDRAULIC WIRE LUFFING TYPE CARGO CRANE AND GRAB 13.5CBM 6 PCS

CARGO HOLDS HATCH COVER

MACGREGOR, HYDRAULIC END FOLDING TYPE

VENTILATION

NATURAL VENTILATION FOR THE CARGO HOLDS

BALLAST HANDLING

BALAST WATER TREATMENT UNIT – BWTS ERMA FIRST FIT MODEL:1000

TPC

ABT 58.18 MT

FLAT FLOOR MEASUREMENT OF CARGO HOLDS AT TANK TOP

LENGTH

MTRS  H

WIDTH(FWD-MTR)

WIDTH(AFT-MTR)

NO 1-

29.48 M

18.5 M

11.72 M

23.50 M

NO 2-

27.02 M

18.5 M

23.50 M

23.50 M

NO 3-

24.60 M

18.5 M

23.50 M

23.50 M

NO 4-

27.02 M

18.5 M

23.50 M

23.50 M

NO 5-

29.38 M

18.5 M

23.50 M

10.96 M

TANK TOP STRENGTH (METRIC TONS PER SQM)

1/3/5 – 23.5 MT

2/4 – 18.7 MT

HATCH DIMENSIONS (ALL FIGS IN METRES)

1- 16.40 X 18.40

2- 19.68 X 18.40

3- 19.68 X 18.40

4- 19.68 X 18.40

5- 19.68 X 18.40
